20 Slimline Panoramic Door
Hidden Linear Track Design
2 Gaskets Fused into 1, No Water/Dust Buildup
20mm Ultra-Narrow Reinforced Hook Rail
Doubles as Sliding Handle, Unobstructed View
4mm Integrated Reinforced Handle
Reinforced Handle
| Category | Technical Parameters | Standard |
|---|---|---|
| Aluminum Mode | 6005-T5 | / |
| Windload Resistance | Class 8 | / |
| Watertightness | Class 6 | / |
| Air Permea bility | Class 7 | / |
| Thermal Insulation | K≤2.0W/(㎡·K) | / |
| Sound Insulation | 35–45dB | / |
| The overall structure adopts a flush frame-sash design for a clean and elegant appearance. |
| Standard German two-component injection bonding technology ensures high connection strength between the doors and windows. |
| High-quality EPDM sealing strips ensure long-term durability and reliable performance. |
| The sash can be opened without removing the insect screen, providing greater convenience in everyday use. |
| The easy-detach portable insect screen makes it the perfect solution for kitchen scenarios. |
| Multiple optional drainage solutions, including concealed drainage and floor-drainage designs, ensure excellent water-tightness of the doors and windows. |
150000㎡ Production Base
Smart Manufacturing 5.0
With ERP Information Management System
Modern Automated Intelligent Production Lines
1000000㎡+
Worry-free Delivery
A: The sash can be opened without opening or removing the insect screen, allowing convenient ventilation while keeping insects out. The easily removable screen can be taken down for cleaning, making it especially suitable for kitchen environments.
A: The KC79W uses 1.8 mm-thick aluminum profiles and German two-component adhesive injection technology for enhanced corner-joint strength. With EPDM gaskets and multiple drainage options, it achieves Class 8 wind load resistance, Class 6 watertightness and Class 7 airtightness.
A:The flush frame-and-sash design and slim 22 mm visible frame create a clean appearance while maximizing natural light and views. Low-E double glazing with an argon-filled cavity and warm-edge spacer provides a thermal transmittance of K ≤ 2.0 W/(m²·K) and sound insulation of 35–45 dB.
