High Rigidity Plug In Multi Deck Aluminum Cargo Body for Heavy Truck

3、Plug-in and rivet connections eliminate welding heat-affected zones and improve sealing performance, making this heavy truck cargo body suitable for demanding transport applications.

Brand :
NewEnergyVehicleParts
Name :
High Rigidity Plug In Multi Deck Aluminum Cargo Body for Heavy Truck
Material Grade :
6082/6061
Temper :
T6
Mechanical Properties :
tensile strengthRm≥290MPa yeild strength Rp0.2≥240MPa elongation延伸率：≥10%
manufacturing process :
Extrusion+CNC+CMT+Powder Coating

Inquiry Now

The multi-deck cargo body is engineered from 6061 or 6082 T6 aluminum alloy with a multi-cavity design that enhances bending rigidity and load-bearing capacity, overcoming the strength limitations of single-layer aluminum.

An extruded reinforced beam structure provides both a high-strength framework and controlled collapse, absorbing impact energy during collisions to protect occupants and cargo.

Plug-in and rivet connections eliminate welding heat-affected zones and improve sealing performance, making this heavy truck cargo body suitable for demanding transport applications.

High Rigidity Plug In Multi Deck Aluminum Cargo Body for Heavy Truck

Category	Technical Parameters	Standard
Product Name	High Rigidity Plug In Multi Deck Aluminum Cargo Body for Heavy Truck	sill beam/sill beam assembly
Material Grade	6082 Aluminum Alloy	High-Strength Grade
Temper	T6	Heat Treated
Tensile Strength	≥ 290 Mpa	Structural Stability
Yield Strength	≥ 240 Mpa	Load-bearing Capacity
Elongation	≥ 10%	Ductility & Toughness
Compatible Module	Customized Dimensions	Large-Format Modules
Manufacturing process	Extrusion+CNC+CMT+Powder Coating

Quality Control

Hardness Testing

HBW hardness testing (≥95) on all extruded beams and panels to verify material strength.

Sealing Performance Test

Water intrusion test is conducted on assembled cargo body to verify excellent sealing at all connection points.

Structural Strength Test

Static load test simulating max cargo weight plus wind-induced vibration test ensures high hardness and durability under heavy-duty use.

Direct Factory Benefits

Capacity

Annual Production Capacity: 70,000 Tons

Customization

Support for Various Length and Cross-section Designs Based on Client Drawings

Packaging

Export-standard Protective Packaging to Prevent Deformation During Sea Freight

Frequently Asked Questions

Q1: s the quality of your products stable? Could there be dimensional variations between batches after mass production?

A: Very stable. Every batch is controlled under ISO/TS 16949, with 100% gauging inspection for critical holes and profiles. We have supplied over millions of sets with a customer complaint rate below 5 %.

Q2: How do you guarantee a 25-year lifespan in corrosive or coastal environments?

A: Normal lead time is 25~30 days. We reserve 20% flexible capacity for rush orders, with fastest delivery in 15 days upon prior agreement(Shipping time not including).

Q3: Do you have enough capacity? If we need 5,000 sets per month for six consecutive months, can you guarantee no supply interruption?

A:Our current monthly capacity is 50,000 sets. 5,000 sets/month is well within our capability, and we can sign an annual supply agreement to secure capacity.
